  105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable

More Views

105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable

Product Videos

  • Low Voltage Electronic Transformer Troubleshooting Guide

105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004 Dimmable

# HD105-120

45 Review(s) | Add Your Review

Sign up for price alert

Electronic 105watt bare wire replacement transformer. 120volt input, 12volt output. Compact easy to use design. Perfect for lighting applications. Dimmable with standard electronic dimmer. Similar to the MDL 316-0004, WH-1051E6A transformer, and the Anchorn Model no: AET-D1051 used in the IKEA fixture as a replacement and SL-728. Relco ETV 105 PF.1/110 RN1248/110

Designer's Note

If you plan to upgrade your halogen fixture to LED bulbs we recommend that you use a transformer made for LED Bulbs and Dimming LED bulbs.
Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps

Availability: Ships in 2-Business day!

$17.50

Specification Sheet & Important Links

jpg
HD Transformer Spec Sheet
(Size: 75.7 KB)
Details
Super small 120volt to 12volt completely encapsulated transformer. Output at 105watts max including line loss. Do not overload. Ships with 6" input and output leads. Please see specification sheet before you order. Similar to MDL 316-0004, WH-1051E6A. Electronic Transformer 105W 120V Input
AC
105
12VAC
ETL approved
Additional Information
Color Black
Warranty 90 Days
Important Note Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps
Primary Breaker No
Secondary Breaker No
Circuits Single
Terminal Block No
Dimmable Any dimmer
Housing Material Plastic
Cross Reference Number MDL 3160004, SL-728 105 watt, Anchorn Model no: AET-D1051, flextecbset 105, MDL Corp, mdl p/n 316-004, Tiella fixture 800RAL5MKN replacement transformer, TST-105. Eurofase 0089 105-Watt, Top Star TST-105W/120V, Topstar TST-105W/120V, Relco ETV 105 PF.1/110 RN1248/110
Approvals ETL
UPC 190202205355
Max Load Wattage 105
Min Load Wattage 20
Input Voltage 120VAC
Output Voltage 12VAC
Electric Current Type AC
Dimensions H x W x L (in) 1.12 X 4.26 X 2
