Details
Intermatic PX100S safety transformer 60Hz 120volt AC 1 Amp input and 12volt / 13volt AC 100 watt output.
Transformer features:
- Stainless steel enclosure
- Mounting brackets located top and bottom of enclosure
- Ten knockouts 1/2in. - 3/4in: (2) right side, (2) left side, (2) back, (4) bottom
- A grounded shield between the primary and secondary windings assures safe operation and the built-in circuit protection will disconnect power to the transformer in case of defect or overload.
- 1 year limited warranty
Additional Information
| Color | Silver |
|---|---|
| Warranty | 90 Days |
| Primary Breaker | Yes |
| Secondary Breaker | Yes |
| Circuits | Single |
| Terminal Block | Yes |
| Dimmable | No |
| Housing Material | Stainless Steel |
| Application | Pool lighting, spa lighting, garden lighting, submersable lights |
| UPC | 078275067561 |
| Max Load Wattage | 100 |
| Input Voltage | 120VAC |
| Output Voltage | 12 / 13VAC |
| Electric Current Type | AC |
| Dimensions H x W x L (in) | 7.25 X 5.25 X 4.5 |
